Operation
INPUT SETTINGS
The INPUT SETTINGS menu gives access to settings of the input mode, the fallback modes and the AES/EBU & AVB gain.
LA4X amplied controllers with HARDWARE INFO ID4 or higher (in MONITORING & INFO menu) support AVB.
‽INPUT SETTINGS ‼※
MONITORING & INFO
OK
‾ABCD INPUT SOURCE ‼※
XLR
‽XLR AB INPUT MODE ‼※
ANALOG
‽XLR CD INPUT MODE ‼※
ANALOG
‽AVB FALLBACK MODE ‼※
OFF
‽AES AB FALLBACK MODE ‼※
OFF
‽AES/EBU & AVB GAIN ‼※
+0.0dB
‽AVB STREAM MAPPING ‼※
1 2 3 4
LA4X amplied controllers with HARDWARE INFO ID1, ID2 or ID3 (in MONITORING & INFO menu) do not
support AVB. These Units can be upgraded to support AVB by purchasing and installing KR LA4XDSP2.
‽INPUT SETTINGS ‼※
MONITORING & INFO
OK
‽XLR AB INPUT MODE ‼※
ANALOG
‽XLR CD INPUT MODE ‼※
ANALOG
‽AES AB FALLBACK MODE ‼※
OFF
‿AES/EBU GAIN ‼※
+0.0dB
ABCD INPUT SOURCE
Compatible LA4X amplied controllers can retrieve four channels from an AVB stream containing up to eight channels, at
48 kHz or 96 kHz, connected by one of the two 1 Gb/s Ethernet ports.
Use ABCD INPUT SOURCE to select between XLR or AVB input sources for all channels.
selecting the input source
‾ABCD INPUT SOURCE ‼※
XLR
OK
ABCD INPUT SOURCE
>XLR<
+ OK
‾ABCD INPUT SOURCE ‼※
AVB NOT CONNECTED
LA4X owner's manual (EN) version 14.1 41
