L-Acoustics LA4X User Manual

Operation
Main menu pages
load a user preset (from memories 1 to 10)LOAD PRESET (p.35)
load a factory preset (from memories 11 to 199)
STORE PRESET (p.37) save the current preset (including current settings) as a user preset (in a memory
from 1 to 10)
DELETE PRESET (p.38) delete a user preset (in memory from 1 to 10)
PRESET PARAMETERS (p.38) set parameters for gain, delay, polarity and input selection
CLEAR GROUP PARAMS (p.40) remove the group parameters dened in LA Network Manager (name, gain,
delay, and Contour EQ)
INPUT SETTINGS (p.41) set the input mode, fallback mode and AES/EBU & AVB gain
MONITORING & INFO (p.49)
display real-time measured values: RMS output voltage and output temperature
(in percentage of the maximum values)
display rmware and preset library versions and amplied controller's MAC
address
launch ENCLOSURE CHECK
OPTIONS (p.52)
set the amplied controller's delay unit, and screen contrast
reset all parameters to factory settings
IP SETTINGS (p.55) set the amplied controller's IP settings (IP address, subnet mask and gateway)
All parameters can also be selected from LA Network Manager. Refer to the LA Network Manager Help.
LOAD PRESET
A preset can be loaded from two pages:
page memory range contents
LOAD PRESET USER 1 to 10 (read and write) User presets stored by user — refer to STORE PRESET (p.37)
LOAD PRESET FACTORY 11 to 199 (read only) Factory preset library created by L-Acoustics and automatically
installed during rmware update (refer to the LA Network
Manager Help)
LA4X owner's manual (EN) version 14.1 35
