Operation
DELETE PRESET
A user preset stored in a user memory (in memory range 1 to 10) can be deleted.
OK
OK
OK
‽DELETE PRESET ‼※
PRESET PARAMETERS
DELETE USER PRESET
002:MY K2
DELETE USER PRESET
ARE YOU SURE?
011:K2 70 100
LF_A LF_A MF_A HF_A
Procedure
1. From the main menu, select DELETE PRESET.
The amplied controller displays NO PRESETS AVAILABLE! when all user memories are empty.
Press the ESC key to cancel.
2. Turn the encoder wheel to select the user memory space.
3. Press the OK key or the encoder wheel to validate.
The amplied controller displays CANNOT DELETE THE CURRENT PRESET, when the selected preset is the
currently loaded preset. It is not possible to delete the currently loaded preset.
Press the ESC key to cancel.
The amplied controller displays ARE YOU SURE?.
4. Press the OK key or the encoder wheel to validate (or press the ESC key to cancel).
PRESET PARAMETERS
The preset parameters include gain, delay, polarity and input selection.
OK
‽PRESET PARAMETERS ‼※
CLEAR GROUP PARAMS
‾GAIN (dB) ‼※
0.0 0.0 0.0 0.0
‽DELAY (ms) ‼※
0.00 0.00 0.00 0.00
‽POLARITY ‼※
+ + + +
‽INPUT SELECTION ‼※
A A B B
‿RESET PRESET ‼※
Gain and delay value ranges
Gain is adjustable from -60 dB to +15 dB.
Delay is adjustable from 0 to 1000 ms — see also section DELAY UNIT (p.52).
Total delay
The total delay includes all group delays (set in LA Network Manager) and the output channel delay. Total delay
cannot exceed 1000 ms.
38 LA4X owner's manual (EN) version 14.1
