L-Acoustics V-DOSC - CO24 Control Output Panel Line Assignments; Table 18 A: CO24 W6 Pin Assignments

L-ACOUSTICS V-DOSC Manual Version 4 6/29/2005 Page 138 of 158
7.5 CO24 Control Output Panel Line Assignments
Table 18a: CO24 W6 Pin Assignments
W6 PIN
#
W6
COLOR
CODE
XLR
#
XLR
PIN
CACOM
CHANNEL
CACOM
PIN
PROCESSOR
CHANNEL
LOUDSPEAKER
ARRAY
42 BLACK A4 3 A C HF LEFT-LEFT
41 RED A4 2 A B HF LEFT-LEFT
40 GND A4 1 A A HF LEFT-LEFT
39 BLACK A3 3 A F MID LEFT-LEFT
38 GREEN A3 2 A E MID LEFT-LEFT
37 GND A3 1 A D MID LEFT-LEFT
36 BLACK A2 3 A J LF LEFT-LEFT
35 YELLOW A2 2 A H LF LEFT-LEFT
34 GND A2 1 A G LF LEFT-LEFT
33 BLACK A1 3 A M SUB LEFT-LEFT
32 ORANGE A1 2 A L SUB LEFT-LEFT
22 GND A1 1 A K SUB LEFT-LEFT
31 RED A6 3 A R 2-WAY FILL HF LEFT-LEFT
30 GREEN A6 2 A P 2-WAY FILL HF LEFT-LEFT
29 GND A6 1 A N 2-WAY FILL HF LEFT-LEFT
28 RED A5 3 A U 2-WAY FILL LF LEFT-LEFT
27 YELLOW A5 2 A T 2-WAY FILL LF LEFT-LEFT
26 GND A5 1 A S 2-WAY FILL LF LEFT-LEFT
25 RED B4 3 B C HF LEFT
24 ORANGE B4 2 B B HF LEFT
23 GND B4 1 B A HF LEFT
21 GREEN B3 3 B F MID LEFT
20 BLUE B3 2 B E MID LEFT
19 GND B3 1 B D MID LEFT
18 GREEN B2 3 B J LF LEFT
17 BROWN B2 2 B H LF LEFT
16 GND B2 1 B G LF LEFT
15 WHITE B1 3 B M SUB LEFT
14 BLUE B1 2 B L SUB LEFT
13 GND B1 1 B K SUB LEFT
12 WHITE B6 3 B R 2-WAY FILL HF LEFT
11 BROWN B6 2 B P 2-WAY FILL HF LEFT
4 GND B6 1 B N 2-WAY FILL HF LEFT
10 BLUE B5 3 B U 2-WAY FILL LF LEFT
9 YELLOW B5 2 B T 2-WAY FILL LF LEFT
8 GND B5 1 B S 2-WAY FILL LF LEFT
7 BLUE REMOTE
OUT
M 4pin XLR
#1
6 ORANGE REMOTE
OUT
M 4pin XLR
#2
5 GND
3 BROWN REMOTE
OUT
M 4pin XLR
#3
2 ORANGE REMOTE
OUT
M 4pin XLR
#4
1 GND
