L-Acoustics V-DOSC - Table 19 B: MD24 W6 Socket Assignments

L-ACOUSTICS V-DOSC Manual Version 4 6/29/2005 Page 141 of 158
Table 19b: MD24 W6 Socket Assignments
W6
Socket
#
W6
COLOR
CODE
CACOM
CHANNEL
CACOM
PIN
PROCESSOR
CHANNEL
LOUDSPEAKE
R
ARRAY
42 BLACK A C HF LEFT-LEFT
41 RED A B HF LEFT-LEFT
40 GND A A HF LEFT-LEFT
39 BLACK A F MID LEFT-LEFT
38 GREEN A E MID LEFT-LEFT
37 GND A D MID LEFT-LEFT
36 BLACK A J LF LEFT-LEFT
35 YELLOW A H LF LEFT-LEFT
34 GND A G LF LEFT-LEFT
33 BLACK A M SUB LEFT-LEFT
32 ORANGE A L SUB LEFT-LEFT
22 GND A K SUB LEFT-LEFT
31 RED A R 2-WAY FILL HF LEFT-LEFT
30 GREEN A P 2-WAY FILL HF LEFT-LEFT
29 GND A N 2-WAY FILL HF LEFT-LEFT
28 RED A U 2-WAY FILL LF LEFT-LEFT
27 YELLOW A T 2-WAY FILL LF LEFT-LEFT
26 GND A S 2-WAY FILL LF LEFT-LEFT
25 RED B C HF LEFT
24 ORANGE B B HF LEFT
23 GND B A HF LEFT
21 GREEN B F MID LEFT
20 BLUE B E MID LEFT
19 GND B D MID LEFT
18 GREEN B J LF LEFT
17 BROWN B H LF LEFT
16 GND B G LF LEFT
15 WHITE B M SUB LEFT
14 BLUE B L SUB LEFT
13 GND B K SUB LEFT
12 WHITE B R 2-WAY FILL HF LEFT
11 BROWN B P 2-WAY FILL HF LEFT
4 GND B N 2-WAY FILL HF LEFT
10 BLUE B U 2-WAY FILL LF LEFT
9 YELLOW B T 2-WAY FILL LF LEFT
8 GND B S 2-WAY FILL LF LEFT
7 BLUE REMOTE IN F 4pin
XLR #1
6 ORANGE REMOTE IN F 4pin
XLR #2
5 GND
3 BROWN REMOTE IN F 4pin
XLR #3
2 ORANGE REMOTE IN F 4pin
XLR #4
1 GND
