7.6 MD24 Multi Distro Panel Line Assignments
Table 19a: MD24 W6 Pin Assignments
W6 PIN
#
W6
COLOR
CODE
CACOM
CHANNEL
CACOM
PIN
PROCESSOR
CHANNEL
LOUDSPEAKER
ARRAY
42 BLACK C C HF RIGHT
41 WHITE C B HF RIGHT
40 GND C A HF RIGHT
39 BLACK C F MID RIGHT
38 BLUE C E MID RIGHT
37 GND C D MID RIGHT
36 BLACK C J LF RIGHT
35 BROWN C H LF RIGHT
34 GND C G LF RIGHT
33 RED C M SUB RIGHT
32 WHITE C L SUB RIGHT
22 GND C K SUB RIGHT
31 RED C R 2-WAY FILL HF RIGHT
30 BLUE C P 2-WAY FILL HF RIGHT
29 GND C N 2-WAY FILL HF RIGHT
28 RED C U 2-WAY FILL LF RIGHT
27 BROWN C T 2-WAY FILL LF RIGHT
26 GND C S 2-WAY FILL LF RIGHT
25 GREEN D C HF RIGHT-RIGHT
24 WHITE D B HF RIGHT-RIGHT
23 GND D A HF RIGHT-RIGHT
21 GREEN D F MID RIGHT-RIGHT
20 YELLOW D E MID RIGHT-RIGHT
19 GND D D MID RIGHT-RIGHT
18 GREEN D J LF RIGHT-RIGHT
17 ORANGE D H LF RIGHT-RIGHT
16 GND D G LF RIGHT-RIGHT
15 WHITE D M SUB RIGHT-RIGHT
14 YELLOW D L SUB RIGHT-RIGHT
13 GND D K SUB RIGHT-RIGHT
12 WHITE D R 2-WAY FILL HF RIGHT-RIGHT
11 ORANGE D P 2-WAY FILL HF RIGHT-RIGHT
4 GND D N 2-WAY FILL HF RIGHT-RIGHT
10 BLUE D U 2-WAY FILL LF RIGHT-RIGHT
9 BROWN D T 2-WAY FILL LF RIGHT-RIGHT
8 GND D S 2-WAY FILL LF RIGHT-RIGHT
7 BROWN REMOTE
OUT
M 4pin
XLR #1
6 YELLOW REMOTE
OUT
M 4pin
XLR #2
5 GND
3 ORANGE REMOTE
OUT
M 4pin
XLR #3
2 YELLOW REMOTE
OUT
M 4pin
XLR #4
1 GND
