L-ACOUSTICS V-DOSC Manual Version 4 6/29/2005 Page 77 of 158
considered to provide a good indication as to the overall coverage of the array in terms of clarity and
intelligibility.
It is also interesting to compare the A-weighted, unweighted and 1-10 kHz SPL mappings of Figure 53
with the individual octave band mappings of Figure 52. The 1-10 kHz SPL mapping is seen to provide a
good representation of the overall coverage of the array and also corresponds well with the coverage
predicted in impact mode. The A-weighted SPL average provides a more strict representation of
system coverage since there is more emphasis on higher frequencies while the unweighted mapping is
more omnidirectional due to the inclusion of lower frequency information in the average.
Note: For color versions of SOUNDVISION figures see the V-DOSC manual PDF file available for download
on
www.l-acoustics.com
Note: A complete description of SOUNDVISION is beyond the scope of this manual. Please refer to the
SOUNDVISION help file and for further information, participation in a V-DOSC or SOUNDVISION Training
Seminar is recommended.
Figure 51: SOUNDVISION Geometric Data for V-DOSC
