ESI-2000
Pilot’s Guide 1-5
Description
OPERATION LIMITS
Pitch, Roll, Yaw: All angles.
Pitch, Roll, Yaw Rate +/- 100 degrees/second
+/- 135 degrees/second (release 1.2)
Altitude: Calibrated Range:
-1,500 to 55,000 ft. / -457 to 16,764 m.
BARO: 27.00 to 32.00 inches Hg.
914 to 1083 hPa or mb
Altitude Rate: Up to ± 6,000 ft/min
Airspeed: Calibrated Range:
Release 1.0:
(Part 23/25 Aircraft) 40 to 400 kts
(Part 27/29 Rotorcraft) 20 to 350 kts
Release 1.1 & 1.2:
Part 23/25 Aircraft 40 to 400 kts or
46 to 460 mph
Part 27/29 Rotorcraft 20 to 350 kts or
23 to 403 mph
Longitudinal Axis
Acceleration: +/- 7.5 g
Lateral Axis
Acceleration: +/- 7.5 g
Vertical Axis
Acceleration: +/- 12.0 g
BATTERY PERFORMANCE
Capacity: Typical: >2 hours
Minimum: 1 hour when temperature is
-15°C to +60°C (5°F to +140°F)
Discharge Temp.
Range: -40°C to 60°C (-40°F to +140°F)
Charging Temp.
Range: 0°C to 45°C (+32°F to +113°F)
Specications (Continued)
