Description
The MAG-3100 and MAG-3000 manufactured by L-3 Avionics Systems are
self contained three-axis magnetometers that provides a three component
measurement of the earth’s magnetic eld. Refer to Figure 1-2 a & b.
If the magnetometer option is used, heading is shown on a tape and digital
readout at the bottom of the display.
Optional Equipment
Figure 1-2a: MAG-3100
Figure 1-2b: MAG-3000
SCHEDULED
MAINTENANCE:
Battery capacity meter requires automated
calibration periodically.
Subject to requirements of FAA document
CFR FAR Part 91.411.
SERVICE LIFE: The indicator has unlimited service life.
The battery has approximately 5 years of
service life; provided that the procedures
for maintenance are followed as detailed
in the Battery Capacity Meter Calibration
Procedure (see page 2-6)
