ESI-2000
Pilot’s Guide 1-3
Description
Specications
PHYSICAL
Size: Bezel: 4.03” x 3.35” (10.24 x 8.51 cm)
Chassis: 3-ATI Opening 7.66” (19.45 cm)
Weight: 2.75 Lbs (1.25 kg) MAX
Power: +28.0 VDC nominal,
10.0 W MAX (battery not charging)
22.0 W MAX (battery charging)
+14.0 VDC (with external converter)
Environmental: DO-160F
Software: DO-178B, Level A
Hardware: DO-254, Level A
Certication:
(FAA and EASA)
TSO-C2d (Type B, [Part 23/25] 40 to 400
kts & [Part 27/29] 20 to 350 kts), and for
Release 1.1 [Part 23/25] 46 to 460 mph,
[Part 27/29] 23 to 403 mph), C3e (Type
II, Slip Only), C4c, C6e, C10b (-1,500 to
55,000 ft), C46a, C113, C179.
ETSO-C2d (Type B, [Part 23/25] 40 to 400
kts & [Part 27/29] 20 to 350 kts),
and for
Release 1.1 [Part 23/25] 46 to 460 mph,
[Part 27/29] 23 to 403 mph),
C3d (Type
II, Slip Only), C4c, C6d,C10b (-1,500 to
55,000 ft), C46a, C113, (Non-ETSO Func-
tion: Rechargeable Lithium Battery Cells
and Lithium Batteries in compliance with
UL 1642 + TSO-C179 appendix 1)
