ESI-2000
Pilot’s Guide1-10
Description
A irspeed Awareness Color Bar (refer to Figure 1-4 and 1-5 a, b, & c)
The airspeed awareness color bar is located along the left side of the
indicated airspeed tape. The color bar indicates critical reference airspeeds
and operating ranges specic to the aircraft.
Part 23/25 Aircraft
Conguration Option: Airspeed Awareness Color Bar may be congured
for V
NE
(cues - V
NE
, V
NO
, V
fe
, V
s1
, V
s0
) or V
MO
(cues - V
MO
, V
fe
, V
s1
, V
s0
)
aircraft. In addition V
mc
and V
yse
may be set up for twin-engine applications.
NOTE
For part 25 Aircraft the Airspeed Awareness Color Bar must
be congured for V
MO
Cues V
fe
, V
s1
, V
s0
, V
mc
and V
yse
may be congured off.
Part 27/29 Rotorcraft
Airspeed Awareness Color Bar may be congured for V
NE
Power On,
V
NE
Power Off and V
CAUTION
(the start of the caution range for airspeed warning).
Cues V
NE
Power On and V
CAUTION
may be congured off.
INDICATED AIRSPEED ( continued )
Airspeed Digital Readout (refer to Figure 1-4)
The odometer styled IAS digital readout is located in the center of the
airspeed tape and displays the current aircraft speed in knots.
Release 1.0. The readout has a viewing range of 40 to 400 kts for Part
23/25 aircraft and 20 to 350 kts for Part 27/29 rotorcraft.
Release 1.1 & 1.2. The readout has a viewing range of 40 to 400 kts (46 to
460 mph). For Part 27/29 Rotorcraft the readout has a viewing range of 20
to 350 kts (23 to 403 mph).
