Avionics Systems
BATTERY SYMBOL QUICK REFERENCE
BATTERY
INDICATOR
DESCRIPTION
Not Shown No information needs to be conveyed to pilot
Green More than 1 hour of operation remains
Amber Less than 1 hour of operation remains
Amber “X” Battery is not available to power unit
(over temp or low battery voltage condition exists)
Red “X” Battery has failed
