L3 Communications MX-15i - Table 1-4 Hand Controller LRU Specification; Table 1-5 GPS Antenna LRU Specification

TM00358 Rev. A Chapter 1 - System LRU Component Specifications
L-3 WESCAM October 2007
All Rights Reserved 7
Storage Humidity 95%, 24 hours
Max Altitude 12 802m (42 000 ft.) above sea level
Max Airspeed 350 Knots indicated airspeed (operational)
425 Knots indicated airspeed (non-operational)
Mounted external to aircraft
Table 1-4 Hand Controller LRU Specification
Item Description Notes
Nomenclature Hand Controller • Part Number: 42228
• Configurations: Single or multi-control
Weight 0.8 kg (1.8 lbs) max per unit Does not include the weight of the cable and
connector
Dimensions 11.4 cm (w) x 21.8 cm (h) x 7.6 cm (d)
(4.5” [w] x 8.6” [h] x 3” [d])
Attached cable length is customer specified.
Input Power +28 VDC Derived from Turret connection.
Environmental
Operating
Temperature
-40°C to 55°C ( -40°F to 131°F)
Storage
Temperature
-55°C to 85°C ( -67°F to 185°F)
Max Altitude < 3353m (<11 000 ft) above sea level Limit for a non-pressurized environment only
Table 1-5 GPS Antenna LRU Specification
Item Description Notes
Nomenclature Omni, hemispherical, low profile antenna Part Number: GPS-511
Weight 0.14 kg (0.3 lbs)
Dimensions 1.5 cm (h) x 8.9 cm (dia) (0.6” [h] x 3.5” [dia])
Input Power +4.0 to +24 VDC
Frequency Band L1 carrier signal
Environmental
Operating
Temperature
-55°C to 85°C (-67°F to 185°F)
Table 1-3 Turret LRU Specifications (Continued)
Item Description Notes
