2.8 EON MENU
The EON menu (electro-optic narrow) provides status information and controls for the EON sensor. Operators can
also access a Level 3 Miscellaneous sub menu for additional diagnostic data in the form of sensor component
temperatures.
Figure 2-25 EON Menu − Levels 2 and 3
Table 2-9 Status Information and Controls in the Level 2 EON Menu
Field Values Description
VALUE FIELDS
LEVEL 0 to 100 Sets the pedestal black level. Default value is 50.
SCENE SETUP DEFAULT Optimizes camera for general purpose setup.
HIGH Optimizes camera for high-contrast scenes.
LOW Optimizes camera for low-contrast scenes.
ACTION FIELDS
MISC – Displays Miscellaneous menu.
ALARMS – Displays Alarms page with BIT test results for the EON sensor.
BIT – Initiates an EON BIT.
DONE – Exits menu.
STATUS INDICATORS
FOV Daylight: 0.28°,
Lowlight: 0.30°
Current horizontal FOV in degrees.
FOCAL LENGTH 1000 mm Current focal length in millimeters.
LEVEL 2 - EON
MODE OPERATIONAL
DONE
ALARMS OK
FOV 0.28 deg
FOCAL LENGTH 1000 mm
FOCUS 150
SENSITIVITY AUTO
TEMP STATUS OK
LEVEL 50
SCENE SETUP DEFAULT
MISC ALARMS BIT
LEVEL 2 - EON
LEVEL 3 - MISCELLANEOUS
TEMPERATURES
AMBIENT 1 22.4 deg C
DONE
PROCESSOR 37.6 deg C
LENS 22.9 deg C
AMBIENT 2 21.8 deg C
CAMERA 35.9 deg C
LL CAMERA HEAD 31.1 deg C
LL CAMERA BODY 25.2 deg C
LL EXT CAMERA BODY 30.4 deg C
FILTER COL
