TM00358 Rev. A Chapter 4 - Turret Shipping Cases & Storage
L-3 WESCAM October 2007
All Rights Reserved 71
Note: When the turret is removed from its shipping case, retain the case in a safe location. The case is intended to
be reused when shipping the turret for depot service or for safe storage as a spare unit.
Unpacking Non-Turret LRU Shipping Packages
1. Inspect the package’s exterior for physical damage. Exterior damage may indicate internal damage to the
contents:
• Report any damage to your supervisor immediately.
2. Open and unpack the package.
3. Inspect each part as you remove it from the case.
• Report any damage to your supervisor immediately.
Table 4-1 Turret Shipping Case & LRU Packaging
Packaging Contents Part Number Qty. Notes
Turret Shipping Case Shipping case 41179 1 • Case weighs approximately
125 kg (276 lbs)
Turret 42390 1
Service stand assembly 42626 1
Service stand, top plate 25705 1
Service stand, mounting
screws
CSNAS1514CA 6 • 6 Cap screws, hex socket –
1/4”-28 x 3/4
Note: Caps are painted red to
designate use for service
stand only.
Service Stand, legs 23216 4
Service stand, leg mounting
screws
1114119 1.00SS 4 • 4 Cap screws, 1/2-13 x 1.00
LRU Packages For example:
• Operator Interface
• Support items and spares
as ordered
Part numbers and weight vary based on support items and spares
ordered.
