Chapter 2 - EON Menu TM00358 Rev. A
October 2007 L-3 WESCAM
38 All Rights Reserved
FOCUS 150m to Infinity Focus position, expressed as an estimated distance to the object that sensor is
focused upon. Units are in meters.
Note: Do not use number for reporting target distance, this is a very crude
distance estimation.
SENSITIVITY AUTO System has been enabled for automatic control of image brightness.
MAN Current value for manual sensitivity. Operators can increment the sensitivity to
control image brightness from the Hand Controller.
TEMP STATUS WARMING UP /
COOLING
Sensor disabled because internal operational temperature is above or below
limits.
OK Sensor at operational temperature.
FILTER LP, XLP, COL Displays the current filter selection. From the Hand Controller, operators can
select between the daylight camera (COL), low-light camera (LP) and a low-light
camera with an extra long pass filter to minimize effects of haze (XLP).
Table 2-9 Status Information and Controls in the Level 2 EON Menu (Continued)
Field Values Description
