34 Controls and Indicators
Hoist Control
The BODY RAISE control switch (see Figure 3-4) is located on the cab console. This 3-position switch
allows the operator to control the body.
When the body is raised, the
TAILGATE UNLOCKED or BODY RAISED warning lamp (see Figure 3-3)
goes on and a buzzer sounds.
Figure 3-4
B
ODY RAISE
control switch
.
Light Bar Control Pad
The light bar control pad allows the operator to activate and deactivate the light bar mounted on the
tailgate.
Figure 3-5
Light bar control pad (left), light bar (right)
Danger!
Always use body safety prop when performing maintenance under a raised body. Failure
to do so may result in severe injury or even death.
