LaCie 12big Rack Storage Server
User Manual page 72
Technical Specifications
11.5. Cooling Fan
Table 75 - Cooling Fans
Number 10
Type Single Rotor High Speed Axial
Speed Control PWM Speed Control in 5 banks of 2
Connection Hot pluggable connector to Enclosure Management Card
Tacho Outputs Individual tacho outputs for each fan
Power Operated from resettable fused 12V from supply rail
11.6. Drive Carrier Module Specification
IMPORTANT INFO: Operating the 12big Rack Storage Server with non-approved drives may invalidate the warranty.
Table 76 - Drive Carrier Module Specification
Module Dimensions 26.6mm H x 106.5 mm W x 220.2 mm D
Weight 0.8 kg (1.0” 300GB drive)
Operating Temperature 5° C to 35° C
Power Dissipation 18 Watts maximum
11.7. Drives
IMPORTANT INFO: Drives should be UL Approved.
11.8. Motherboard
Standard ATX form factor with integral I/O panel.
