POST
13.5. Memory Initialization Error
Codes
These codes are shown on the motherboard LEDs as described in
section 13.1. Introduction.
Table 87 - Memory Initialization Error Codes
Checkpoint Description
E8 Memory Error - No memory installed.
EA Memory Error - DDR3 initialisation.
EB Memory Error - Memory test.
ED Memory Error - RDIMMs and UDIMMs
are mixed.
EE Memory Error - Invalid memory popu-
lation.
EF Memory Error - Memory structure
problem.
13.6. FPGA Status Codes
Table 88 - FPGA Status Codes
LED Color Meaning
ID Blue Enclosure identification
D7 Green ATX PSU power good
D6 S4 state#
D5 SLP S3#
D4 1.5V and 1.1V valid
D3 CPU0 and CPU1
1
Vcore valid
D2 CPU0 and CPU1
1
VDDQ valid
D1 CPU0 and CPU1
1
VTT valid
D0 CPU0 and CPU1
1
1.8V valid
1
– Applies to whichever CPU(s) are present.
