5: Configuration Using Web Manager
UDS2100 Device Server User Guide 34
Connect Protocol
From the drop-down menu, select TCP.
Connect Mode: Passive Connection
Select Yes to accept incoming connections. The default
setting is Yes.
Determines whether a password is required for an incoming
passive connection. This field is not available when a
password is set for Telnet mode. The default setting is No.
If Password Required was set to Yes, enter the password
for passive connections.
Pass Through
Disable or enable the UDS’s ability to send the escape
sequence. The default is Yes (send the escape sequence).
Connect Mode: Active Connection
Select None (default) to disable Active Connect. Otherwise,
indicate the connection type from the drop-down list:
With Any Character: Attempts to connect when any
character is received from the serial port.
With Active Mdm Ctrl In: Accepts external connection
requests only when the Modem Control In input is asserted.
With Start Character: Attempts to connect when it receives
a specific start character from the serial port. The default
start character is carriage return.
Manual Connection: Attempts to connect when directed by
a command string received from the serial port.
Auto Start: Automatically connects to the remote IP
address and port after booting up.
If Active Connect is set to With Start Character, enter the
start character in this field. The default setting is 0D.
Indicates the on-screen response type when in Modem Mode
(if Modem Mode is enabled). The default setting is None.
RING
Indicates whether to display the remote IP address upon
connection. The default setting is Yes.
Endpoint Configuration
Enter the local port number.
active connect
Select to auto-increment the local port number for new
outgoing connections. The range of auto-incremented port
numbers is 50,000 to 59,999 and loops back to the beginning
when the maximum range is reached. Disabled by default.
Enter the remote port number.
Enter the IP address of the remote device.
Common Options
This field is available for configuration only when Active
Connect is set to None. Select Enable to permit Telnet
To Next Page
