Lantronix UDS2100 User Manual

UDS2100 Device Server User Guide 9
1: Using This Guide
Purpose and Audience
This guide provides the information needed to configure, use, and update the
UDS2100 device server. It is for system administrators and those responsible for
installing and maintaining the UDS.
Chapter Summary
The remaining chapters in this guide include:
Chapter Description
2: Introduction
Describes the main features of the UDS and the protocols it
supports.
3: Installation of UDS2100
Provides information for installing your unit and getting it up and
running using DeviceInstaller or a serial port connection.
4: Using DeviceInstaller
Instructions for viewing the current configuration using
DeviceInstaller.
5: Configuration Using Web
Manager
Details using the Web Manager to set parameters such as port
and server properties.
6: Configuration via Telnet or
Serial Port (Setup Mode
Provides instructions for accessing Setup Mode (command line
interface) using a Telnet connection through the network or a
terminal or terminal emulation program through the serial port.
7: Setup Mode: Server
Configuration
Details the network (server) settings
8: Setup Mode: Channel
Configuration
Details the serial port settings.
9: Setup Mode: Advanced
Settings
Details expert and security settings and explains how to reset the
unit to factory default values.
10: Firmware Upgrades
Provides instructions for obtaining the latest firmware and updating
the UDS.
11: Monitor Mode
Provides instructions for accessing and using the command line
interface to monitor the network and diagnose problems.
A: Troubleshooting and
Contact Information
Describes common problems and error messages and how to
contact Lantronix Technical Support.
B: Connections and Pinouts
Provides descriptions and illustrations of connection hardware.
C:Technical Specifications
Lists technical specifications for the UDS.
D: Mounting Brackets
Provides drawings and dimensions of the unit's mounting brackets.

Lantronix UDS2100 Specifications

General

Isolation	1.5 kV
Certification	FCC, C/UL, CSA, VCCI, CE, TUV, CTick
Serial interface type	RS-232/422/485
Serial ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Electrostatic Discharge (ESD) protection	15 kV
USB 2.0 ports quantity	0
Supported network protocols	ARP, UDP, TCP, ICMP, Telnet, TFTP, AutoIP, DHCP, HTTP, SNMP TCP, UDP, Telnet, TFTP, RFC2217
Built-in processor	Lantronix DSTNI-EX
Processor frequency	48 MHz
Compatible operating systems	Windows 98/ME/NT/2000/XP
Flash memory	2 MB
RAM capacity	0.256 MB
LED indicators	LAN, Y
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	10 - 90 %
Input voltage	9 - 30 V

Weight and Dimensions

Weight	400 g
Dimensions (WxDxH)	72 x 23 x 95 mm
