Lantronix UDS2100 User Manual

11: Monitor Mode
UDS2100 Device Server User Guide 70
Table 11-1. Monitor Mode Commands
Command
Command Name
Function
VS x.x.x.x
Version
Queries software header record (16 bytes) of unit
with IP address x.x.x.x.
GC x.x.x.x
Get Configuration
Gets configuration of unit with IP address x.x.x.x as
hex records (120 bytes).
SC x.x.x.x
Send Configuration
Sets configuration of unit with IP address x.x.x.x
from hex records.
PI x.x.x.x
Ping
Pings unit with IP address x.x.x.x to check device
status.
AT
ARP Table
Shows the unit’s ARP table entries.
TT
TCP Connection
Table
Shows all incoming and outgoing TCP connections.
NC
Network Connection
Shows the unit’s current IP address, gateway,
subnet mask, and DNS server.
RS
Reset
Resets the unit’s power.
QU
Quit
Exits diagnostics mode.
G0, G1, ....,Ge, Gf
Get configuration
from memory page
Gets a memory page of configuration information
from the device for setup record 0 to15.
S0, S1,...,Se, Sf
Set configuration to
memory page
Sets a memory page of configuration information
on the device for setup record 0 to15.
R0, R1, ....,Rb, Rc
Get configuration
from memory page
Gets a memory page of configuration information
from the device for setup record 16 to28.
W0, W1, ....,Wb,
Wc
Set configuration to
memory page
Sets a memory page of configuration information
on the device for setup record 16 to 28.
GM
Get MAC address
Shows the unit's 6-byte MAC address.
SS
Set Security record
Sets the Security record without the encryption key
and length parameters. The entire record must still
be written, but the encryption-specific bytes do not
need to be provided (they can be null since they
are not overwritten).
SA
Scan
Initiates a wireless scan if the wireless interface is
enabled. Reports any stations found, including
BSSID, SSID, and RSSI. If SA is followed by a
string, the string is used to filter SSIDs before
reporting. If the BSS does not broadcast its SSID,
only the BSSID and RSSI are returned.
NS
Network Status
Reports the network interfaces’ statuses. Includes
potentially negotiated parameters like speed/duplex
for Ethernet or BSSID, encryption, authentication
for wireless interfaces.
co
Set IP address, host
bits, gateway, and
DNS server IP
Example:
co 192.168.0.10 8 192.168.0.1 10001 192.168.1.10
with
192.168.0.10 = IP address of the UDS

Lantronix UDS2100 Specifications

General

Isolation	1.5 kV
Certification	FCC, C/UL, CSA, VCCI, CE, TUV, CTick
Serial interface type	RS-232/422/485
Serial ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Electrostatic Discharge (ESD) protection	15 kV
USB 2.0 ports quantity	0
Supported network protocols	ARP, UDP, TCP, ICMP, Telnet, TFTP, AutoIP, DHCP, HTTP, SNMP TCP, UDP, Telnet, TFTP, RFC2217
Built-in processor	Lantronix DSTNI-EX
Processor frequency	48 MHz
Compatible operating systems	Windows 98/ME/NT/2000/XP
Flash memory	2 MB
RAM capacity	0.256 MB
LED indicators	LAN, Y
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	10 - 90 %
Input voltage	9 - 30 V

Weight and Dimensions

Weight	400 g
Dimensions (WxDxH)	72 x 23 x 95 mm
