2: Introduction
UDS2100 Device Server User Guide 12
Figure 2-1. Serial Tunneling Example
The Com Port Redirector software available for download at
www.lantronix.com/support/downloads
simplifies the integration process by
extending the functionality of COM-port-based Windows™ applications. Virtual
COM ports, mapped to remote device servers on the network, can replace direct
serial connections.
Figure 2-2. Direct TCP/IP or Redirector Configuration
Note: For step-by-step instructions on configuring the UDS for serial tunneling or for use
with the Com Port Redirector, see UDS Configuration Tutorials on the Lantronix web site:
www.lantronix.com/support
.
