4: Using DeviceInstaller
XPress™ DR Industrial Device Server User Guide 23
Current Settings Description
Hardware Address
Non-configurable field. Displays the XPress device server’s hardware (or MAC)
address.
Firmware Version
Non-configurable field. Displays the firmware currently installed on the XPress
device server.
Extended Firmware
Version
Non-configurable field. Displays the extended firmware currently installed on
the XPress device server.
Online Status
Non-configurable field. Displays the XPress device server’s status as online,
offline, unreachable (the XPress device server is on a different subnet), or busy
(the XPress device server is currently performing a task).
IP Address
Non-configurable field. Displays the XPress device server’s current IP address.
To change the IP address, see Assigning an IP Address.
IP Address was
Obtained
Non-configurable field. Displays “Dynamically” if the XPress device server
automatically received an IP address (e.g., from DHCP). Displays “Statically” if
the IP address was configured manually. If the IP address was assigned
dynamically, the following fields appear:
 Obtain with DHCP with value of True or False
 Obtain with BOOTP with value of True or False
 Obtain with RARP with value of True or False
 Obtain with Auto IP with value of True or False
Subnet Mask
Non-configurable field. Displays the XPress device server’s current subnet
mask. To change the subnet mask, see Assigning an IP Address.
Gateway
Non-configurable field. Displays the XPress device server’s current gateway.
To change the gateway, see Assigning an IP Address.
Number of COB
partitions supported
Non-configurable field. Displays the number of COB partitions supported.
Number of Serial
Ports
Non-configurable field. Displays the number of serial ports on the XPress unit.
TCP Keepalive
Non-configurable field. Displays the XPress device server’s TCP keepalive
value. The value is in the range 1-65s, and the default setting is 45.
Telnet Supported
Non-configurable field. Indicates if Telnet sessions are permitted. Displays
True.
Telnet Port
Non-configurable field. Displays the XPress device server’s port for telnet
sessions.
Web Port
Non-configurable field. Displays the XPress device server’s port for Web
Manager configuration.
Maximum Baud Rate
Supported
Non-configurable field. Displays the XPress unit’s maximum baud rate.
Note: The XPress device server may not currently be running at this rate.
Firmware Upgradable
Non-configurable field. Displays True, indicating the XPress device server’s
firmware is upgradable as newer version become available.
Supports
Configurable Pins
Non-configurable field. Displays False.
Supports Email
Triggers
Non-configurable field. Displays False.
Supports AES Data
Stream
Non-configurable field. Displays False.
Supports 485 Non-configurable field. Displays True. The XPress DR supports the RS-485
protocol.
Supports 921K Baud
Rate
Non-configurable field. Displays
False
.
Supports HTTP
Server
Non-configurable field. Displays True.
Supports HTTP Setup Non-configurable field. Displays True.
