NOTE: Lars Thrane A/S has an Interface Control Document (ICD) with details describing the
following content: binary and text formats, remote management (configuration, requesting
position report, and trigger position report). In order to support the Thrane (binary) format
it is a requirement to get access to this ICD.
The trigger configuration options and intervals are summarized in Table 30.
The time and distance trigger conditions can be configured individually. A tracking report will be sent, when
a trigger condition has been met - time and/or distance. The trigger algorithm will ‘reset’ every time a
tracking report has been sent.
The time trigger condition can be configured from 1 minute (0:01) and up to 7 days (168:00). The distance
trigger condition can be configured from 0.1 NM and up to 999.0 NM. For the distance trigger condition, it
is possible to configure a Minimum time interval, which has the purpose to make sure that not too many
tracking reports are sent.
Example: If the distance interval is configured to 5.0 NM and Minimum time interval is configured to 01:00
hour, then position reports will be sent, when both requirements have been met (maximum every 1 hour).
If the speed over ground is < than 5 knots, then a tracking report will be sent every 5.0 NM. If the speed
over ground is > 5 knots, then a tracking report will be sent every 1 hour.
Under Options - Send report on power-on it is possible to configure the LT-3100 system to send a tracking
report every time the terminal is powered on.
Use the button Send report now, illustrated in Figure 156 on page 117, to overwrite the tracking algorithm
and send a tracking report instantly. Also, use the button to test the format of the tracking reports after
tracking configurations have been applied.
NOTE: The LT-3110 Control Unit UI display has a tracking window (MENU -> System -> Tracking),
providing tracking status overview. From this tracking window, it is possible to initiate a
periodic tracking report (if configured) or initiate a tracking message, which will be sent to
either an SMS or Email destination. For further details see Tracking on page 71.
Trigger Configurations
Trigger
Format
Interval
Comments
Time
Time interval
HH:MM
0:01 to 168:00
Time can be configured from 0.01 (1
minute) to 168:00 (up to 7 days)
Distance
Distance interval
NM
0.1 to 999
Distance can be configured from 0.1 to
999 NM
Minimum time interval
HH:MM
0:01 to 168:00
Minimum time can be configured from
0.01 (1 minute) to 168:00 (up to 7 days)
Table 30: Web server – Tracking (trigger configurations)
