LARSON Bass - Helm and Control Switches; Ignition Switch; Battery Switch

BOAT FEATURES AND OPTIONS
SECTION
9
© 2003-2018 Ken Cook Co. 9 - 14 l Bass
HELM AND CONTROL SWITCHES
The following information is intended as basic and typical and may not apply to
your specific application. Not all switches may be covered in this section. See the
Manufacturer’s Operator’s Manual for specific information on the use and operation
of switches in the boat.
Many of the electrical features and systems in the boat are equipped with a control
switch and protected with breakers or fuses. Switches are designed for different
applications and found in many styles and shapes. Some switches may have a
lighted indicator for easy ON/OFF identification. Some switch panels contain a
master power switch that controls power to all circuits.
IGNITION SWITCH
The ignition switch controls the engine starter circuit, the engine ignition system
and accessory circuits connected to the ignition switch.
BATTERY SWITCH
Battery switches are used to control battery power distribution and disconnect the
batteries from the boat’s electrical system. Battery switches are designed in many
styles and for different applications. They generally provide battery isolation when
used with multiple batteries and are used primarily as a method of quick and
positive battery disconnection. Battery switches also protect against tampering,
electrical fire hazards and battery drain. Keep this switch off when not using the
boat or when storing it for extended periods of time.
Do not turn off the battery switch with the engine running;
this could damage the engine’s charging system.
Consult a qualified, knowledgeable technician for proper operation of the boat’s
specific electrical system.
ON
OFF
KCB-0006
1 & 2
OFF
12
ONE BATTERY
TWO BATTERIES
TYPICAL BATTERY SWITCHES
