BD5 is mounted on the tube as describet in
appendix 1-2.. The sensor is mounted on the
valve bracket as shown, through the existing
holes above the filter . Both the tube end and
the sensor cord should go out from beneath the
sensor.
The tube goes through the hole in the valve
bracket and is connectet to the pump
Upgrade kit BOM:
2 x M3x12 allen screws pn: 00219147
