PowerTrace Serial User´s Guide 1 3
©1989-2018 Lauterbach GmbH
A PowerTrace Serial tool connector
B Selector for adapter configuration mode for RX path
C Selector for adapter configuration mode for TX path
D Configuration switches for equalizer and deemphasis for groups of lanes (RX and TX)
E Selector for adapter configuration mode for RX path
F Selector for protocol specific behavior for RX path
G Selector for termination style for RX path
H Selector for adapter configuration mode for TX path
J Selector for protocol specific behavior for RX path
K Selector for termination style for TX path
L Selector for EEPROM configuration
M PCIe-device-present
O Target connector
A
B
F
K
J
M
D
E
H
L
O
G
C
