PowerTrace Serial User´s Guide 1 4

A target setup could look like this:

NOTE: It could be necessary to give mechanical support to the 80pin cable on its way

from tool to target.

LED Function

RX DONE On: RX register configuration done

Off: RX register configuration in progress, failed or target not powered

TX DONE On: TX register configuration done

Off: TX register configuration in progress, failed or target not powered

NOTE: The adapter configuration of RX buffers and TX buffers is pipelined. The TX

configuration can only succeed if RX configuration was successful.
