Lauterbach PowerTrace Serial User Manual

PowerTrace Serial User´s Guide 1 6
©1989-2018 Lauterbach GmbH
RXTERM Termination behavior during signal detection.
Default: Open.
Open: unlimited cyclic RX test, Hi-Z during test then 50
Set 1-2: limited cyclic RX test, Hi-Z during test then 50
Set 2-3: manual test with 50 termination
PCIe MODE Emphasis/deemphasis configuration
Default: Open
Set 1-2: PCIe Gen3 without Deemphasis
Set 2-3: PCIe Gen3 with Deemphasis
Set 2-4: PCIe Gen1+2
Open: Auto detection of driver parameter
TX Jumper Function
SCL SEL Must be set to 2-3.
Set 1-2: SMB mode
Set 2-3: Pin mode
SDA SEL Must be set to 2-3.
Set 1-2: SMB mode
Set 2-3: Pin mode
TXTERM Termination behavior during signal detection.
Default: Open.
Open: unlimited cyclic RX test, Hi-Z during test then 50
Set 1-2: limited cyclic RX test, Hi-Z during test then 50
Set 2-3: manual test with 50 termination
PCIe MODE Emphasis/deemphasis configuration
Default: Open
Set 1-2: PCIe Gen3 without deemphasis
Set 2-3: PCIe Gen3 with deemphasis
Set 2-4: PCIe Gen1+2
Open: Auto detection of driver parameter
RX Jumper Function
