Sentinel Plus Press Brake Guarding System Operation Manual LS-CS-M-073
Page 33
Original Language Version: 1.04 Released: 19/07/2017
The User level menu does not require an access code, and can be accessed by anyone
operating the machine.
The Supervisor level menu requires an access code. This menu contains parameters that
configure how the Sentinel Plus system and the User Interface Panel operate. This menu
should only be accessible to suitably trained and authorized personnel.
The System menu requires an access code. (This is the highest level access code, and can
also be used to access the Supervisor level menu). This menu contains machine/site
specific parameters that are set during the installation of the Sentinel Plus Press Brake
Guarding System. The System menu is not described in this document.
Warning:
The System menu does not contain any user configurable parameters.
System menu parameters must only be configured by trained and
qualified Sentinel Plus installers. Setting incorrect parameter values
may render your machine inoperable.
Once a menu has been selected the parameters can be navigated, selected and edited.
The parameters are stored in non-volatile memory that is maintained even when the
Sentinel Plus system is powered down. Refer to Section 8 for detailed instructions on how
to navigate and configure the User and Supervisor menus.
Note:
When any menu screen is selected, the safety application running on the PGS-3
turns off the enable outputs, and the machine cannot run. If the foot pedal is
pressed, the LCD display on the PGS-3 will show the Condition Code 40A1.
5.6.1 User Guides
The User Guides are navigated in the same way as menus, using the arrow buttons. The
arrow buttons step through the list of guides; the desired guide is then selected by pressing
the ENTER button. Refer to Section 8.1.1 for a description of how to navigate menus.
This leaves the User Guide and returns to the User Guide list. See
Figure 5-2 for an overview of the menu system.
Selects the next page in the guide.
Selects the previous page in the guide.
Table 5-4: User Guide Buttons
The User Guides are simple, step by step graphical guides for common procedures that
need to be performed regularly on the Sentinel Plus system, such as the block laser tool
alignment procedure.
If the guide contains more than one page the left/right arrow keys can be used to navigate
the pages of the guide.
