Sentinel Plus Press Brake Guarding System Operation Manual LS-CS-M-073
Page 8
Original Language Version: 1.04 Released: 19/07/2017
1 About This Manual
This section contains information about this manual. It contains the following sections:
• Document Objectives.
• Technical Competence Requirements.
• Document Organisation.
• Related Documentation.
• Guides to Notes, Cautions and Warnings.
• Obtaining Technical Assistance.
1.1 Document Objectives
This manual provides information about the operation of the Lazer Safe Sentinel Plus Press
Brake Guarding System.
1.2 Technical Competence Requirements
All operators of the Sentinel Plus Press Brake Guarding System should be trained in its
use, and the press brake upon which it is installed in a manner that complies with
established safety practices.
1.3 Document Organisation
This manual is organised into the following chapters:
1. About This Manual.
2. Critical Safety Information.
3. System Overview.
4. LZS-005-R Operation.
5. The Sentinel Plus User Interface Panel.
6. System Operation.
7. Light Curtain Mode (Optional).
8. User and Supervisor Menus.
9. Operator Instruction and Demonstration.
10. Maintenance.
11. Glossary of Terms.
1.4 Related Documentation
This manual (Sentinel Plus Press Brake Guarding System Operation Manual) should be
used in conjunction with the following documents:
• Lazer Safe Sentinel Plus Press Brake Guarding System Installation Manual (LS-CS-
M-074).
• Lazer Safe Block Laser Alignment Guide (LS-CS-M-025 Rev 2.0).
• Lazer Safe Laser Distortion Causes and Solutions Manual (LS-CS-M-057).
• Safety of Machine Tools – Hydraulic Press Brakes EN12622:2009.
• Safety Requirements for Power Press Brakes ANSI B11.3 – 2012.
• Code for Power Press Operation: Health, safety and safeguarding requirements
CSA Z142-10.
