Lazer Safe SENTINEL PLUS - Parameter 4 - Language; Parameter 5 - Guard Type Selection

Sentinel Plus Press Brake Guarding System Operation Manual LS-CS-M-073
Page 56
Original Language Version: 1.04 Released: 19/07/2017
Use the ► button to navigate the digits, and the ▲▼ buttons to change each digit value.
Changes can be abandoned at any time by pressing the  button. When the desired digit
has been set press the ENTER button, the value will be written into the panel’s non-volatile
memory, and the system will return to the parameter list.
8.3.5 Parameter 4 – Language
The language displayed by the Sentinel Plus User Interface is set in the Language menu.
Use the ▲▼ buttons to navigate the options. Changes can be abandoned at any time by
pressing the  button. When the desired option has been selected, press the ENTER
button, the value will be written into the panel’s non-volatile memory, and the system will
return to the parameter list.
8.3.6 Parameter 5 – Guard Type Selection
The Sentinel Plus system has the option of supporting light curtain optical protection. If light
curtains have been installed and configured this parameter is used to switch between the
planar lasers and the light curtains. The parameter has two options:
• Laser Protection. Enables the Lazer Safe LZS-005-R optical protection (and
disables the light curtains).
• Light Curtain. Enables the OEM light curtain optical protection (and disables Lazer
Safe laser guarding).
Use the ▲▼ buttons to navigate the options. Changes can be abandoned at any time by
pressing the  button. When the desired option has been selected, press the ENTER
button, the value will be written into the panel’s non-volatile memory, and the system will
return to the parameter list.
Refer to Section 7 for further details of Light Curtain mode operation.
