Leakwise SLC-220 - User Manual

Questions and Answers

S
Sheila BaileyAug 13, 2025
What to do if the Leakwise SLC-220 Controller LCD and power light are off?
- E
  Eric HoweAug 13, 2025
  If the LCD and/or power light are off, and there's no 4-20mA output or relay output change, check the following: * Verify the connection to the mains or power source and ensure the internal on-off switch is on. * Confirm the power supply conforms to the required specifications. * Check the wiring against the wiring diagram. * Inspect the relays: if the small LED on the left side of the relay doesn't change as expected, replace the faulty relay or the outputs board.
B
bradfordjessicaAug 20, 2025
How to fix a Leakwise SLC-220 Controller showing an OIL indication when there is no oil?
- E
  Eric JacksonAug 21, 2025
  If your Leakwise Controller indicates oil presence when there is no oil, consider these potential causes and solutions: * Ensure the sensor is installed vertically. * If the sensor "jumps" due to turbulence, install the sensor assembly in a stilling tube or increase the response delay. * Check for and carefully release any entanglement of the flexible cable between the sensor and the stilling cage. * Recalibrate the system.
J
Joseph FordAug 25, 2025
What to do if remote recorder receives less than 20mA from Leakwise Controller?
- A
  April KellyAug 25, 2025
  If the remote recorder receives less than 20mA when 20mA is expected, check the following: * Verify the analog output settings according to chapter 2.2.3. * Ensure the load is below 400 ohms; reduce it if necessary.
S
sandra53Aug 27, 2025
Why Leakwise SLC-220 won't communicate with PC using SLC-Manager?
- A
  Anthony YoungAug 27, 2025
  If you are experiencing communication issues between the Leakwise Controller and the PC with the SLC-Manager program, consider the following: * Verify that the serial port is set to 115200 Baud, 8 data bits, 1 stop bit, no parity, and no flow control. * Check the integrity of the communication cable and ensure correct connection of Tx and Rx wires (straight connection, not crossed).
C
Christopher JonesSep 1, 2025
Why isn't the Leakwise SLC-220's light or LCD indication changing with liquid status?
- C
  colemanjohnSep 1, 2025
  If a change in liquid status does not result in the appropriate lights or LCD indication, consider the following: * Ensure the liquid level is not less than the level specified in the Sensor Test Certificate. * Recalibrate the system. * Check and correctly set up the lights according to chapter 4.5.
D
Dennis FullerSep 4, 2025
What causes relay malfunctions in Leakwise SLC-220 Controller when the LED is OK?
- M
  monica09Sep 4, 2025
  If the relay malfunctions while the corresponding relay LED tracks the expected state, the cause may be a faulty relay. Replace the outputs board.
N
Nancy MonroeSep 8, 2025
What to do if Leakwise SLC-220 Controller relay malfunctions and LED doesn't track the state?
- M
  Michael CunninghamSep 8, 2025
  If the relay malfunctions and the corresponding relay LED does not track the expected state, the sensor thresholds or relay setup may be set improperly. Correct the settings.
A
Angela CookNov 15, 2025
Why is the FAIL indicator on for my Leakwise Controller?
- N
  Nathan CampbellNov 15, 2025
  The FAIL indicator may be on due to several reasons: * A faulty sensor. Check each channel to identify the faulty one. Try connecting the sensor to a known good channel to isolate the problem. * Improperly connected sensor. Verify the sensor cables against the wiring diagram. * Sensor out of calibration. Ensure the sensor signal is within the AIR and WATER limits; otherwise, recalibrate the channel. * Abnormal signal output from the sensor due to malfunction. Disconnect the sensor, connect it to an external 12 VDC power supply, and measure the DC current. Compare the readings to the Sensor Test Certificate. If they don't match, contact your distributor. * If safety barriers are installed, a safety barrier failure may have occurred. Check the resistance between points 1 and 3 of ...

Summary

SLC-220 General Description

Block Diagram

Visual representation of SLC-220 components and connections, illustrating system architecture.

SLC-220 Installation and Wiring

Mounting and Wiring the SLC-220

Instructions for physically mounting the SLC-220 unit and connecting its various cables.

Connecting the Power Cable

Details on connecting the power supply to the SLC-220 unit for different voltage types.

Connecting Sensor Cables

How to connect sensor wires to the SLC-220 terminal block TB10 for signal input.

Connecting Analog Outputs

Connecting Relay Outputs

RS-485 SCADA Port Connection

PC RS-232 Serial Port Connection

How to connect a PC for setup, calibration, and monitoring using the RS-232 port.

SLC-Manager Software Usage

Program Installation

Steps for installing the SLC-Manager software on a PC.

Entry Screen Overview

Main Sensors View Screen

Sensor Settings Screen

Allows viewing and modifying parameters for individual sensors.

SLC-220 General Settings

Optional GSM Modem Communication

Configuration Messages

Calibration Messages

Commands for setting calibration points, season, and performing auto-calibration via SMS.

SLC-220 Troubleshooting Guide

Appendix C: Firmware Update Procedure

Leakwise SLC-220 Specifications

General

Manufacturer	Leakwise
Model	SLC-220
Power supply	24 VDC
Display	LCD
Type	Controller
Product Type	Controller
Communication	RS-485, Modbus
Operating temperature	-20 to +60 °C
Input Channels	Up to 8
Outputs	Relay outputs (alarm, system failure)
Enclosure Rating	IP66
