12. Technician Password: Initial password is 1234.
13. Power Supply Voltage: Indication of voltage supply to the Main board, for viewing only.
Save PC Time and Date: If checked, the time & date from the PC will be sent to the SLC-220
when pressing the Save to SLC button.
Save to SLC button: Writes the updated parameters to the SLC-220 unit, and updates the View
Parameters column of the left.
Load from SLC button: Reads the existing parameters from the SLC-220 unit for viewing and
changing if necessary.
Save to PC button: Writes the updated parameters to the PC as a xml file.
Load from PC button: Reads parameters from a xml file in the PC for viewing and changing if
necessary, and for saving a file to the SLC-220 if necessary.
Exit (Back) button: Return to the Main Sensors View screen.
Notes:
1. In each screen where parameter where changed, press Save to SLC button or Save to
PC button (as appropriate) BEFORE changing to a different screen or exiting the
program.
2. It is recommended to have the parameters saved also to the PC for future reference.
3. When a parameter is changed, it is colored red until it is saved to the SLC or to the PC.
4. After the parameters are saved on the SLC-220 controller, the on-board Buzzer will
confirm it with a single beep, or reject the data by sounding multiple beeps.
