3-8 FAA APPROVED 4-30-76
REISSUED 2-25-81, CHANGE 14
DUAL GENERATOR FAILURE
1. Electrical Load — Reduce.
a. COOL-FAN Switch — OFF.
b. AUX HT Switch (if installed) — OFF.
c. On aircraft incorporating AAK 86-1 or SB 35/36-21-17,
W/S AUX HEAT DEFOG Switch — OFF.
2. L and R IGN & ST Circuit Breakers (main power bus) Check and
reset.
3. START-GEN Switches — GEN.
START-GEN switch must be in GEN for the respective
generator RESET switch to be effective.
4. GEN RESET Switches Depress momentarily.
Depressing and holding the GEN RESET switch longer
than one-half second, or multiple activations, may cause
damage to the electrical system.
If Generators Do Not Reset:
5. Turbine Speed (N
2) 80% RPM or above.
6. START-GEN Switches — OFF, then GEN.
7. GEN RESET Switches Depress momentarily.
If Generators Do Not Reset:
8. START-GEN Switches — OFF.
9. JET PUMP Switches — Check, ON.
10. Both FUEL CMPTR Switches OFF, one at a time. Control
engines manually.
Engine response will be much slower with the fuel
computers OFF.
Monitor Fan Speed (N
1) indicators. If an engine ac-
celerates uncontrolled, immediately set applicable
FUEL CMPTR switch(es) — On.
11. If there is fuel in the fuselage tank:
Aircraft not equipped with FUS VALVE switch:
a. FUS TANK XFER-FILL Switch — XFER.
b. FUSLG PMP Circuit Breaker (copilot’s main bus) Pull.
Aircraft equipped with FUS VALVE switch:
a. FUS VALVE Switch — OPEN.
Approximately 162 pounds of fuselage fuel will be un-
usable.
12. Land as soon as practical.
NOTE
CAUTION
CAUTION
NOTE
3-8 FAA APPROVED 4-30-76
REISSUED 2-25-81, CHANGE 14
DUAL GENERATOR FAILURE
1. Electrical Load — Reduce.
a. COOL-FAN Switch — OFF.
b. AUX HT Switch (if installed) — OFF.
c. On aircraft incorporating AAK 86-1 or SB 35/36-21-17,
W/S AUX HEAT DEFOG Switch — OFF.
2. L and R IGN & ST Circuit Breakers (main power bus) — Check and
reset.
3. START-GEN Switches — GEN.
START-GEN switch must be in GEN for the respective
generator RESET switch to be effective.
4. GEN RESET Switches — Depress momentarily.
Depressing and holding the GEN RESET switch longer
than one-half second, or multiple activations, may cause
damage to the electrical system.
If Generators Do Not Reset:
5. Turbine Speed (N
2) — 80% RPM or above.
6. START-GEN Switches — OFF, then GEN.
7. GEN RESET Switches — Depress momentarily.
If Generators Do Not Reset:
8. START-GEN Switches — OFF.
9. JET PUMP Switches — Check, ON.
10. Both FUEL CMPTR Switches — OFF, one at a time. Control
engines manually.
Engine response will be much slower with the fuel
computers OFF.
Monitor Fan Speed (N
1) indicators. If an engine ac-
celerates uncontrolled, immediately set applicable
FUEL CMPTR switch(es) — On.
11. If there is fuel in the fuselage tank:
Aircraft not equipped with FUS VALVE switch:
a. FUS TANK XFER-FILL Switch — XFER.
b. FUSLG PMP Circuit Breaker (copilot’s main bus) — Pull.
Aircraft equipped with FUS VALVE switch:
a. FUS VALVE Switch — OPEN.
Approximately 162 pounds of fuselage fuel will be un-
usable.
12. Land as soon as practical.
NOTE
CAUTION
CAUTION
NOTE
