LeCroy 9300C Series

A–9
9344C Series, 9350C Series, 9354C Series
Ø 9344C Series, 9350C Series, 9354C Series
Signal Capture
Acquisition System Bandwidth (-3 dB):
Ø 9344C Series
Ø @ 50 Ω: DC to 500 MHz
Ø 100 mV/div: 400 MHz
Ø 50 mV/div and below: 350 MHz
Ø @ 1 MΩ: DC to 500 MHz typical at tip of optional
FET probe AP020
Ø 9350C/9354C Series:
Ø @ 50 Ω: DC to 500 MHz
100 mV/div: 400 MHz
50 mV/div and below: 350 MHz
Ø @ 1 MΩ: DC to 500 MHz typical at tip of optional
FET probe AP020
Number of Channels:
Ø 9344C/9354C Series: four
Ø 9350C Series: two
Number of Digitizers:
Ø 9344C/9354C Series: four
9350C Series: two
9344C Series
MEMORY PER CHANNEL
(IN POINTS) PER MODEL
CHANNELS USED
(PEAK DETECT ON/OFF)
MAX SAMPLE RATE
C CM CL
ACTIVE CHANNELS
All (Peak Detect Off) 250 MS/s 50k 250k 2M All
100 MS/s data
25k
data
100k
data
1M
data
All (Peak Detect ON)
200 MS/s peak
25k
peak
100k
peak
1M
peak
All
Two Channels Paired
(Peak Detect OFF)
500 MS/s 100k 500k 4M CH 2 and CH 3
Four Channels Combined
(Peak Detect OFF)
1000 MS/s 250k 500k 4M CH 2
