LeCroy 9300C Series

A–10
Specifications
9350C/9354C Series
MEMORY PER CHANNEL
(IN POINTS) PER MODEL
CHANNELS USED
(PEAK DETECT ON/OFF)
MAX SAMPLE RATE
C CM CL
ACTIVE CHANNELS
All (Peak Detect OFF) 500 MS/s 50k 250k 2M All
100 MS/s data
25k
data
100k
data
1M
data
All
All (Peak Detect ON)
400 MS/s peak
25k
peak
100k
peak
1M
peak
2.5 ns peak detect
9350C/M/L 9354C/M/L
Two Channels Paired
(Peak Detect OFF)
1 GS/s 100k 500k 4M
CH 1 CH 2 + CH 3
FOUR-CHANNEL MODELS ONLY
Four Channels Combined
by PP092 Adapter
(Peak Detect OFF)
2 GS/s 250k 1M 8M CH 2 (PP092 input)
9354CTM
All (Peak Detect OFF) 500 MS/s 500 000 All
Two Channels Paired
(Peak Detect OFF)
1 GS/s 1M CH 2 and CH 3
100 MS/s data 250k data All
All Peak Detect ON
400 MS/s peak 250k peak 2.5 ns peak detect
Four Channels Combined
by PP092 Adapter
(Peak Detect OFF)
2 GS/s 2M CH 2 (PP092 input)
Sensitivity: 2 mV/div to 5 V/div, fully variable
Scale Factors: Wide range of probe attenuation factors
Offset Range:
Ø 2.00–9.9 mV/div: ±120 mV
Ø 10.0–199 mV/div: ±1.2 V
Ø 0.2–5.0 V/div: ±24 V
DC Accuracy: typically 1%
Vertical Resolution: 8 bits
Bandwidth Limiter: 30 MHz
Input Coupling: AC, DC, GND
