A–11
9344C Series, 9350C Series, 9354C Series
Input Impedance: 50 Ω ±1 % or 1 MΩ//15 pF (system
capacitance using PP002)
Max. Input:
Ø 50 Ω: ±5 V DC (500 mW) or 5 V rms
Ø 1 MΩ: 250 V max (DC + peak AC ≤10 kHz)
Acquisition Modes Random Interleaved Sampling (RIS): For repetitive signals
from 1 ns/div to 2 µs/div
Ø 9344C Series, 9350CM/CL, 9354CM/CL/CTM: For
repetitive signals from 1 ns/div to 5 µs/div
Single shot:
Ø 9344C Series: For transient and repetitive signals from
20 ns/div (all channels active)
Ø 9350C, 9354C Series: For transient and repetitive
signals from 10 ns/div (all channels active)
Peak Detect:
Ø 9344C Series: Captures and displays 5 ns glitches and
other high-speed events
Ø 9350C, 9354C Series: Captures and displays 2.5 ns
glitches and other high-speed events
Sequence: Stores multiple events in segmented acquisition
memories
Deadtime Between Segments: =80 µs
Number of Segments Available:
Model Segments
9344C
9350C 9354C 2–200
9344CM 9350CM 9354CM 9354CTM 2–500
9344CL 9350CL 9354CL 2–2000
Timebase System Timebases: Main and up to four Zoom Traces
Time/Div Range: 1 ns/div to 1000 s/div
Clock Accuracy: =10 ppm
Interpolator resolution: 10 ps
Roll Mode:
Ø 9344C: Ranges 500 ms–1000 s/div
Ø 9350C, 9354C Series: Ranges 500 ms–1000 s/div; >50
000 points: 10–1000 s/div
External Clock: =100 MHz on EXT input with ECL, TTL or zero
crossing levels
