A–18
Specifications
Ø 9370C Series, 9374C Series
Signal Capture
Acquisition System Bandwidth (-3 dB):
Ø @ 50 Ω: DC to 1 GHz
10 mV/div and above
Ø @ 1 MΩ: DC to 500 MHz typical
at PP005 probe tip
Ø 1 GHz FET probe optional
Number of Channels, Digitizers:
Ø 9374C Series: four
Ø 9370C Series: two
Sensitivity:
Ø 50 Ω: 2 mV/div to 1 V/div, fully variable
Ø 1 MΩ: 2 mV/div to 10 V/div, fully variable
Scale Factors: Wide range of probe attenuation factors
9370C/9374C Series
MEMORY PER CHANNEL
(POINTS)
Model
CHANNELS USED
(PEAK DETECT ON/OFF)
MAX SAMPLE
RATE
C CM CTM CL
ACTIVE CHANNELS
All (Peak Detect OFF) 500 MS/s 50k 250k 500k 2M All
100 MS/s data
25k
data
100k
data
250k
data
1M
data
All
All (Peak Detect ON)
400 MS/s peak
25k
peak
100k
peak
250k
peak
1M
peak
2.5 ns peak detect
9370C/M/L 9374C/M/L/TM
Two Channels Paired
(Peak Detect OFF)
1 GS/s 100k 500k 1M 4M
CH 1 CH 2 + CH 3
FOUR-CHANNEL MODELS ONLY
Four Channels Combined
by PP093 Adapter
(Peak Detect OFF)
2 GS/s 250k 1M 2M 8M One (PP093 input)
