A–19
9370C Series, 9374C Series
Offset Range:
Ø 2.00–4.99 mV/div: ±400 mV
Ø 5–99 mV/div: ±1 V
Ø 0.1–1 V/div: ±10 V
Ø 1–10 V/div: ±100 V (1 MΩ Only)
DC Accuracy: typically 1%
Vertical Resolution: 8 bits
Bandwidth Limiter:
Ø 25 MHz
Ø 200 MHz
Input Coupling: AC, DC, GND
Input Impedance: 50 Ω ±1 %, or 1 MΩ//15 pF typical, system
capacitance at tip of PP005 probe
Max. Input:
Ø 50 Ω: ±5 V DC (500 mW) or 5 V rms
Ø 1 MΩ: 400 V max (DC + peak AC ≤10 kHz)
Acquisition Modes Random Interleaved Sampling (RIS): For repetitive signals
from 1 ns/div to 5 µs/div
Single shot: For transient and repetitive signals from 10 ns/div
(all channels active)
Peak Detect: Captures and displays 2.5 ns glitches and other
high-speed events
Sequence: Stores multiple events in segmented acquisition
memories
Deadtime Between Segments: =80 µs
Number of Segments Available:
Model Segments
9370C 9374C 2–200
9370CM 9374CM 2–500
9370CL 9374CL 9374CTM 2–2000
Timebase System Timebases: Main and up to four Zoom Traces
Time/Div Range: 1 ns/div to 1000 s/div
Clock Accuracy: ≤10 ppm
Interpolator resolution: 10 ps
