A–21
9370C Series, 9374C Series
Pattern:
Ø Two-channel models: Triggers on the logic combination of
the three inputs CH 1, CH 2 and EXT Trigger, where each
source can be defined as High, Low or Don’t Know and the
trigger as the pattern’s beginning or end
Ø Four-channel models: Triggers on the logic combination of
the five inputs CH 1, CH 2, CH 3, CH 4 and EXT Trigger,
where each source can be defined as High, Low or Don’t
Know and the trigger as the pattern’s beginning or end
Autosetup AUTOSETUP button: Sets timebase, trigger and sensitivity to
display wide range of repetitive signals — amplitude 2 mV–40 V;
frequency above 50 Hz; duty cycle greater than 0.1%
Autosetup Time: Around two seconds
Vertical Find: Automatically sets sensitivity and offset
Probes Probe Model: One PP005 probe supplied per channel (10:1,
10 MΩ//11 pF, 500 V max input); FET probes, purchased
separately, fully compatible with entire scope series
Probe calibration: Max 1 V into 1 MΩ, 500 mV into 50 Ω,
frequency and amplitude programmable, pulse or square wave
able to be selected, rise and fall time 1 ns typical (calibrator also
offers trigger or Pass/Fail output)
Signal Viewing
Display CRT: 12.5 x 17.5 cm (9” diagonal)
raster
Resolution: 810 x 696 points
Grids: 1, 2, or 4 grids.
Formats: YT, XY and both together
Graticules: Internally generated;
separate intensity control for grids and
waveforms
Waveform Style: Vectors, which can be switched on and off,
connect individual sample points highlighted as dots
Modes: Normal, XY, Variable or Infinite Persistence
Real-time Clock: Date, hours, minutes, seconds
