A–22
Specifications
Vertical Zoom: Up to 5x Vertical Expansion (50x with averaging,
up to 40 µV sensitivity, with optional WP01 Advanced Waveform
Math Package)
Horizontal Zoom: Waveforms can be expanded to give 2–2.5
points/div.
Model Zoom Factor
9370C 9374C 2000x
9370CM 9374CM 10 000x
9374CTM 50 000x
9370CL 9374CL 100 000x
Signal Analysis
Waveform Processing Processing functions: Add,
Subtract, Multiply, Divide, Negate,
Identity, Summation Averaging, and
Sine x/x; four functions performable
at one time
Average: Summed averaging of up to
1000 waveforms in the basic instrument;
up to 10
6
averages possible with optional WP01 Advanced
Waveform Math Package
Extrema: Roof, Floor or Envelope values of from 1 to 10
6
waveforms — with WP01 Option
ERES: Low-Pass digital filter provides up to 11 bits vertical
resolution; sampled data always available, even when trace turned
off; any of above modes usable without destroying data — with
WP01 Option
FFT: Spectral Analysis with five windowing functions and FFT
averaging, with optional WP02 Spectrum Analysis Package
Histogramming and Trending: With optional WP03 Parameter
Analysis Package, in-depth diagnostics on waveform parameters
Internal Memory Waveform Memory: Up to four 16-bit Memories (M1, M2, M3, M4).
Processing Memory: Up to four 16-bit Waveform Processing
Memories (A, B, C, D).
Setup Memory: Four non-volatile memories; optional cards or
disks for high-capacity waveform and setup storage
