A–23
9370C Series, 9374C Series
Cursor Measurements Relative Time: Arrow cursors measure time and voltage
differences relative to each other
Relative Voltage: Horizontal bars measure voltage differences up
to ±0.2% full-scale in single-grid mode
Absolute Time: Cross-hair marker measures time relative to trigger
and voltage with respect to ground
Absolute Voltage: Reference bar measures
voltage with respect to ground
Interfacing Remote Control: By GPIB and RS-232-C for
all front-panel controls, internal functions
RS-232-C Port: Asynchronous up to
115.2 Kb/s for computer or terminal
control, or printer or plotter connection
GPIB Port: (IEEE-488.1) Configurable as
talker/listener for computer control and fast
data transfer; command language compliant with IEEE-488.2
Centronics Port: Hardcopy interface
PC Card (PCMCIA II/III Ports): Optional for memory cards, flash
cards and removable hard disks
Floppy Disk: High density 3.5-inch
floppy disk drive (DOS format)
Hardcopy: TIFF and BMP formats
available for import to Desktop
Publishing programs; printers and plotters: HP DeskJet, HP
ThinkJet, QuietJet, LaserJet, PaintJet, and EPSON printers; HP
7400 and 7500 series, or HPGL compatible plotters
Ø Optional internal, high-resolution graphics printer
Output Formats: Binary, or ASCII waveform output compatible
with spreadsheets, MATLAB, Mathcad
General Auto-calibration: Ensures specified DC and timing accuracy
Temperature: 5 to 40 °C (41 to 104 °F) rated
Humidity: 80 % for temperatures up to 31 °C, decreasing
linearly to 50 % relative humidity at 40 °C
Altitude: Up to 2000 m (6560 ft) operating, 40 °C max
Power: 90–250 V AC, 45–66 Hz, 230 W
Battery Backup: Front-panel settings maintained for two years
Dimensions: (HWD) 8.5 x 14.5 x 16.25 inches / 264 x 397 x
453 mm
Weight: 13 kg (28.6 lb.) net, 18.5 kg (40.7 lb.) shipping
Warranty: Three years
Conformity EMC: EN 50082-1 conformity
