A–27
9384C Series
DC Accuracy: typically 1% at 10 mV and above
Vertical Resolution: 8 bits
Bandwidth Limiter:
Ø 25 MHz
Ø 200 MHz
Input Coupling: AC, DC, GND
Input Impedance: 50 Ω ±1 %, or 1 MΩ//11 pF typical
Max. Input:
Ø 50 Ω: ±5 V DC
Ø 1 MΩ: 400 V max (DC + peak AC ≤10 kHz)
Acquisition Modes Random Interleaved Sampling (RIS): For repetitive signals
from 1 ns/div to 2 µs/div
Single shot: For transient and repetitive signals from 1 ns/div
(all channels active)
Peak Detect: Captures and displays 2.5 ns glitches and other
high-speed events
Sequence: Stores multiple events, time-stamped, in segmented
acquisition memories
Deadtime Between Segments: =80 µs
Number of Segments Available:
Model Segments
9384C 2–500
9384CM 9384CTM 9384CL 2–2000
Timebase System Timebases: Main and up to four Zoom Traces
Time/Div Range: 1 ns/div to 1000 s/div
Clock Accuracy: ≤10 ppm
Interpolator resolution: 10 ps
Roll Mode:
Ø Ranges 500 ms–1000 s/div
Ø For >50 000 points: 10–1000 s/div
Triggering System Modes: Normal, Auto, Single, and Stop
Sources: CH1, CH2, CH3, CH4, Line, Ext, Ext/10; Slope, Level
and Coupling able to be set independently
Slope: Positive, Negative
Coupling: AC, DC, HF, LFREJ, HFREJ
Pre-trigger Recording: 0–100 % of full scale adjustable in 1 %
increments
