A–28
Specifications
Post-trigger Delay: 0–10 000 divisions adjustable in 0.1 div
increments
Holdoff by Time: 10 ns–20 s
Holdoff by Events: 0–99 999 999 events
Internal Trigger Range: ±5 div
EXT Trigger Max Input:
Ø 50 Ω ±1 %: ±5 V DC (500 mW) or 5 V rms
Ø 1 MΩ/15 pF: 400 V max. (DC + peak AC ≤10 kHz)
EXT Trigger Range: ±0.5 V (±5 V with Ext/10)
Trigger Timing: Trigger Date and Time listed in “Memory
Status” menu
SMART Trigger Types Signal or Pattern Width: Triggers on width between two limits
of between <2.5 ns (1 ns typical) or pulse widths between
<2.5 ns and 20 s exclusive
Signal or Pattern Interval: Triggers on interval between two
limits of between 10 ns and 20 s
Dropout: Triggers if the input signal drops out for a time-out
longer than 25 ns–20 s
State/Edge Qualified: Triggers on any source only if a given
state or transition — number of events, time interval — on
another source
TV: Selection of both line (up to 1500) and field number (up to
8) for PAL, SECAM, NTSC or nonstandard video
Exclusion Trigger: Triggers only on shorter-than-normal
(defined) aberrations
Pattern: Triggers on the logic combination of the five inputs CH
1, CH 2, CH 3, CH 4 and EXT Trigger, where each source can
be defined as High, Low or Don’t Know and the trigger as the
pattern’s beginning or end
Autosetup AUTOSETUP button: Sets timebase, trigger and sensitivity to
display wide range of repetitive signals — amplitude 2 mV–40 V;
frequency above 50 Hz; duty cycle greater than 0.1%
Autosetup Time: Around two seconds
Vertical Find: Automatically sets sensitivity and offset
Probes Probe Model: One PP005 probe supplied per channel (10:1,
10 MΩ//11 pF, 500 V max input); FET probes, purchased
separately, fully compatible with entire scope series
Probe calibration: Max 1 V into 1 MΩ, 500 mV into 50 Ω,
frequency and amplitude programmable, pulse or square wave
