A–29
9384C Series
able to be selected, rise and fall time 1 ns typical (calibrator also
offers trigger or Pass/Fail output)
Signal Viewing
Display CRT: 12.5 x 17.5 cm (9” diagonal)
raster
Resolution: 810 x 696 points
Grids: 1, 2, or 4 grids.
Formats: YT, XY and both together
Graticules: Internally generated;
separate intensity control for grids and
waveforms
Waveform Style: Vectors, which can be
switched on and off, connect individual sample points highlighted as
dots
Modes: Normal, XY, Variable or Infinite Persistence
Real-time Clock: Date, hours, minutes, seconds
Vertical Zoom: Up to 5x Vertical Expansion (50x with averaging,
up to 80 µV sensitivity, with optional WP01 Advanced Waveform
Math Package)
Horizontal Zoom: Waveforms can be expanded to give 2–2.5
points/div.
Model Zoom Factor
9384C 2000x
9384CM 9384CTM 10 000x
9384CL 80 000x
Signal Analysis
Waveform Processing Processing functions: Add,
Subtract, Multiply, Divide, Negate,
Identity, Summation Averaging, and
Sine x/x; four functions performable at
one time
Average: Summed averaging of up to 1000
