LeCroy 9300C Series

D–10
Appendix D
Parameter and what it does Definition Notes
period
Period of a cyclic signal measured as
time between every other pair of 50 %
crossings. Starting with first transition
after left cursor, period is measured for
each transition pair, with values averaged
to give final result.
( )
∑
=
−
Mr
i
ii
TrTr
Mr
1
5050
1
(See Fig. D–2)
Where: Mr is the number of
leading edges found, Mf the
number of trailing edges
found,
x
i
Tr the time when rising
edge i crosses the x % level,
and
x
i
Tf the time when falling
edge i crosses the x % level.
pkpk
Peak–to–peak: Difference between
highest and lowest points in waveform.
Unlike ampl, does not assume the
waveform has two levels.
maximum -
minimum
(See Fig. D–1)
Gives a similar result when applied to
time domain waveform or histogram
of data of the same waveform. But
with histograms, result may include
contributions from more than one
acquisition.
phase
Phase difference between signal analyzed
and signal used as reference.
Phase difference
between signal
and reference
points
Number of points in the waveform between
the cursors.
Number of points
between cursors
(See Fig. D–2)
r20–80%
Rise 20 % to 80 %: Duration of pulse
waveform's rising transition from 20% to
80%, averaged for all rising transitions
between the cursors.
Average duration
of rising 20–80 %
transition
On signals NOT having two
major levels (triangle or saw-
tooth waves, for example), top
and base can default to
maximum and minimum,
giving, however, less
predictable results.
r@level
Rise at level: Duration of pulse
waveform's rising edges between
transition levels.
Duration of rising
edges between
transition levels
On signals NOT having two
major levels (triangle or saw-
tooth waves, for example), top
and base can default to
maximum and minimum,
giving, however, less
predictable results.
rise
Rise time: Measures time between two specified
values on waveform’s rising edge (10–90 %). Rise
times for each edge averaged to give final result.
Time at upper
threshold - Time at
lower threshold
averaged over each
rising edge
(See Fig. D–1)
On signals NOT having two
major levels (triangle or saw-
tooth waves, for example), top
and base can default to
maximum and minimum,
giving, however, less
predictable results.
