OPERATOR’S MANUAL
WRXi-OM-E Rev C 17
• Interpolation: Linear, (sinx)/x
Triggering System
• Modes: Normal, Auto, Single, and Stop
• Sources: Any input channel, External, Ext/10, or line; slope and level are unique to each source (except line)
• Coupling Mode: GND, DC 50 ohms, DC 1 Mohms, AC 1 Mohms
• Pre-trigger Delay: 0 to 100% of memory size (adjustable in 1% increments or 100 ns)
• Post-trigger Delay: 10,000 divisions in real time mode; limited at slower time/div settings
• Holdoff by Time or Events: 1 ns to 20 s or from 1 to 99,999,999 events
• Internal Trigger Range: ±4.1 div from center (typical)
• Trigger and Interpolator Jitter: </= 3 ps
rms
(typical)
• Maximum Trigger Sensitivity with Edge Trigger (Ch1-4 + external):
44Xi 64Xi 62Xi 104MXi/Xi 204Xi
2 div @ < 400 MHz
1 div @ < 200 MHz
2 div @ < 600 MHz
1 div @ < 200 MHz
2 div @ < 600 MHz
1 div @ < 200 MHz
2 div @ < 1 GHz
1 div @ < 200 MHz
2 div @ < 2 GHz
1 div @ < 200 MHz
• Maximum Trigger Frequency with SMART Trigger (Ch1-4 + external):
44Xi 64Xi 62Xi 104MXi/Xi 204Xi
400 MHz
@ >/= 10 mV
600 MHz
@ >/= 10 mV
600 MHz
@ >/= 10 mV
1 GHz
@ >/= 10 mV
2 GHz
@ >/= 10 mV
• Trigger Level DC Accuracy: ±4% of full scale ±2 mV (typical)
• External Trigger Range: EXT/10 ±4 V; EXT ±400 mV
Basic Triggers
• Edge/Slope/Line: Triggers when the signal meets the slope and level condition.
• Width: Triggers on positive or negative pulse widths selectable from 500 ps to 20 s or on intermittent faults
(subject to bandwidth limit of oscilloscope).
• Pattern: Logic combination (AND, NAND, OR, NOR) of 5 inputs (4 channels and external trigger input – 2
Ch+EXT on WaveRunner 62Xi). Each source can be high, low, or don’t care. The High and Low level can be
selected independently. Triggers at start or end of the pattern.
• State or Edge Qualified: Triggers on any input source only if a defined state or edge occurred on another
input source. Delay between sources is selectable by time or events.
• TV: Provides stable triggering on standard or custom composite video signals. Use them on PAL, SECAM, or
NTSC systems. Optional HDTV Trigger for 1080i, 1080p and 720p formats along with non-standard formats
up to 2000 lines.
SMART Triggers
• Dropout: Triggers if the input signal drops out for longer than a selectable time-out between 1 ns and 20 s.
• Glitch: Triggers on positive or negative glitches with widths selectable from 500 ps to 20 s or on intermittent
faults (subject to bandwidth limit of oscilloscope).
• Signal or Pattern Interval: Triggers on intervals selectable from 1 ns to 20 s.
• Runt: Trigger on positive or negative runts defined by two voltage limits and two time limits. Select between 1
ns and 20 s.
• Slew Rate: Activates a trigger when the rising or falling edge of a pulse crosses two threshold levels, an
