WAVERUNNER XI SERIES

18 WRXi-OM-E Rev C

upper level and a lower level.

Automatic Setup

• Autosetup: Automatically sets timebase, trigger, and sensitivity to display a wide range of repetitive signals.

• Vertical Find Scale: Automatically sets the vertical sensitivity and offset for the selected channels to display

a waveform with maximum dynamic range.

Probes

• Probes: One PP008 probe per channel standard (WR104MXi, WR104Xi, WR204Xi: one PP007 per channel);

optional passive and active probes are available.

• Probe System - ProBus: Automatically detects and supports a wide variety of compatible probes

• Scale Factors: Automatically or manually selected depending on probe used

Color Waveform Display

• Type: Color 10.4-inch flat panel TFT LCD with high resolution touch screen

• Resolution: SVGA; 800 x 600 pixels; maximum external monitor output resolution of 2048 x 1536 pixels

• Real Time Clock: Date, hours, minutes, and seconds displayed with waveform; accurate to ±50 ppm; SNTP

support to synchronize to precision internet clocks

• Number of Traces: Maximum of eight traces; simultaneously displays channel, zoom, memory, and math

traces

• Grid Styles: Single, Dual, Quad, Octal, XY, Single+XY, Dual+XY

• Waveform Display Styles: Sample dots joined or dots only

Analog Persistence Display

• Analog and Color-graded Persistence: Variable saturation levels; stores each trace's persistence data in

memory

• Persistence Selections: Select analog, color, or 3-D

• Trace Selection: Activate Analog Persistence on all or any combination of traces

• Persistence Aging Time: From 500 ms to infinity

• Sweeps Displayed: All accumulated or all accumulated with last trace highlighted

Zoom Expansion Traces

Display up to 4 Math/Zoom traces

Internal Waveform Memory

Waveform: M1, M2, M3, M4 (Store full-length waveforms with 16 bits/data point.) Or save to any number of files

(limited only by data storage media).

Setup Storage

Front Panel and Instrument Status: Save to the internal hard drive or to a USB-connected peripheral device.
